R3H Core
Particular
o | Ietm | Winding | Wire Size (T.C.W) | Impedance( Ω )min | |||
10MHz | 25MHz | 100MHz | 200MHz | ||||
1 | R6H 6×10-13 | 1.5 | 250 | 0.57 | 90 | ||
2 | R6H 6×10-04 | 1.5 | 150 | 210 | 0.57 | 470 | 340 |
3 | R6H 6×10-13 | 2 | 350 | 0.57 | 480 | ||
4 | R6H 6×10-04 | 2 | 200 | 330 | 0.57 | 570 | 300 |
5 | R6H 6×10-13 | 2.5 | 495 | 0.57 | 540 | ||
6 | R6H 6×10-04 | 2.5 | 280 | 415 | 0.57 | 640 | 295 |
7 | R6H 6×10-13 | 3 | 640 | 0.5 | 535 | ||
8 | R6H 6×10-04 | 3 | 355 | 515 | 0.5 | 630 | 275 |
ΦA | D | ΦC |
6±0.25 | 10±0.4 | 0.8±0.1 |
