EFD Core
Particular
| 磁芯型号 | 尺寸Dimensions(mm) | 有效参数Effective Parameter | AL(nH/N2)±25% | AL(nH/N2)±30% | |||||||||||
| Core Type | A | B | C | D | E | F | CL/A (mm-1) | Ae (mm2) | Le (mm) | Ve (mm3) | 重量Weight(g) | FP40 | FH5K | FH7K | FH10K |
| EP6/6/4 | 6.0±0.15 | 2.8±0.05 | 3.9+0-0.25 | 1.7±0.1 | 4.3min | 2.0±0.1 | 3.08 | 3.0 | 9.2 | 27.0 | 0.42 | 380 | 800 | 1200 | 1400 |
| EP7/7/6 | 7.35±0.2 | 3.55±0.2 | 5.85±0.2 | 3.05+0-0.15 | 6.0min | 2.4±0.2 | 1.52 | 10.3 | 15.7 | 163.0 | 0.83 | 930 | |||
| EP9/8/7 | 9.2±0.2 | 3.75±0.2 | 6.35±0.2 | 3.3±0.15 | 7.4±0.2 | 2.65±0.2 | 1.52 | 10.0 | 15.7 | 160.0 | 1.4 | 1000 | 2200 | 2400 | 3500 |
| EP11.5/10/8 | 11.5±0.3 | 5.1±0.2 | 7.7±0.2 | 3.3±0.2 | 9.4±0.2 | 3.8±0.2 | 10.68 | 11.0 | 18.5 | 203.0 | 2.9 | 1000 | 1920 | 4000 | 5300 |
| EP13/13/9 | 12.5±0.3 | 6.5±0.2 | 8.8±0.2 | 4.4±0.2 | 10.0±0.3 | 4.7±0.2 | 1.18 | 19.7 | 23.2 | 457.0 | 4.9 | 1600 | 3200 | 5500 | 7350 |
| EP18/17/11 | 18.1±0.4 | 8.4±0.4 | 11.0±0.3 | 5.7±0.2 | 12.0±0.4 | 5.7±0.2 | 0.8 | 33.6 | 26.8 | 899.0 | 12.3 | 1840min | |||
| EP24/21/16 | 24.0±0.5 | 10.7±0.2 | 15.0±0.4 | 8.8±0.3 | 16.5±0.4 | 7.2±0.2 | 0.48 | 78.9 | 37.6 | 2961.0 | 29.0 | 5000 | |||
